MFD.BY: Superior DATE MFD: 1992 TYPE: Firetube. Packaged. Steam generating boiler. STEAM PRODUCTION-PPH: 6900 SIZE-HP: 200 STEAM PRESSURE: 150 psig operating when supplied w/212°F feedwater. STEAM TEMPERATURE: 350 deg F approx. SUPERHEATER: NA ECONOMIZER: NA BURNER: Seminole mdl.6X-1250 Burner with Iron Fireman mdl BSD-G-12.5 control, 12.5MM Btu/Hr max, 3.1-10.5 normal. COMBUSTION BLOWER: 10HP approx. 3/60/460v. Controls 1/60/120v TUBES: 1250 SF area CERTIFICATION: ASME NB AUXILIARIES: Valve trim available- LWCO, drain valve, water guage, water column blowdown valve, vent and drain valves, safety valves,150#, Steam pressure guage, plus other valve trim and regulators. PRIOR SERVICE: Plant steam package. COMMENTS: Shell 1/2" thick. 3/4" thick head. Installed indoors prior service. Water treatment package available. SHIPPING SIZE-W X H X L: 7'W X 8'H X 20'L APPROX. WEIGHT-LBS: 20000# QUANTITY: 2
