- MFD.BY:Bird Machine Co., Walpole, Mass.
- DATE MFD:1968
- TYPE:Decanter horizontal Solid bowl, Contour design, 2/3 phase separation liquid/solid.
- MODEL:4500
- MAT'LS. CONSTRN-BOWL ASS'Y:304SS
- MAT'LS. CONSTRN-CONVEYOR:304SS
- CONVEYOR-LEADS:5" pitch, single lead.
- BOWL SIZE:32'' X 50''
- BOWL CONTOUR:15°/3° contour section approx. 12" long at 15° and 12" long at 3° taper. Parallel section approx. 25" long
- STYLE:Right hand. Gearbox located at solids discharge end driven by v-belts from liquids discharge/large end.
- DRIVEN BY:75HP 3/60/440V motor.
- DRIVEN VIA:V-Belt. Planetary gear 80:1, Type SA56 w/torque arm
- BACKDRIVE:NA
- PRIOR SERVICE:Used, reported in excellent condition.
- COMMENTS:Approx. 2" pool depth. No hardsurfacing. Includes gearbox guard, feed pipe, base assembly, belt guard.
- SHIPPING SIZE-W X H X L:4'W X 4'H X 8'L
- APPROX. WEIGHT-LBS:12000#
- QUANTITY:1
