- MFD.BY:Bird Machine Co.
- DATE MFD:1977 approx.
- TYPE:Decanter horizontal solid bowl, 2 phase separation liquid/solid
- MODEL:7700
- MAT'LS. CONSTRN-BOWL ASS'Y:CS
- MAT'LS. CONSTRN-CONVEYOR:CS
- CONVEYOR-LEADS:18" double lead.
- BOWL SIZE:54" X 70” contour
- BOWL CONTOUR:15/3° [tbc] Cylinder 28.8", Conical 41.2".
- DRIVEN BY:200HP. [Rated 150-400HP, per OEM] 3/60/480 V (motor not attached)
- DRIVEN VIA:Gearbox SA56 [tbc]. Max torque 250-350000FT.lbs.
- BACKDRIVE:NA
- BOWL SPEED:550 RPM max approx. 226 X G.
- PRIOR SERVICE:Coal 55-100TPH
- COMMENTS:Base is carbon steel. Normal solids capacity 50-100TPH. Feed pipe 8" dia.
- SHIPPING SIZE-W X H X L:8'W X 7'H X 16'L
- APPROX. WEIGHT-LBS:35400#
- QUANTITY:1
