- MFD.BY:Titan
- DATE MFD:1995
- TYPE:Belt. Troughed
- BELT WIDTH:24"
- BELT LENGTH:30' long between end roll centerlines, frame assembled in 2 sections
- CONFIGURATION:Horizontal, 30deg troughed belt idlers.
- MAT'L. CONSTRN-BELT:2 ply Goodyear Pylon 2100B belt or similar
- DRIVEN BY:5HP 3/60/230- 460V, approx.
- DRIVEN VIA:Shaft mounted reducer.
- PRODUCT DENSITY:70 lbs/cu.ft. approx.
- PRIOR SVC:Waste water filter press system, dry solids take off.
- COMMENTS:Belt height 24" bottom of trough to bottom of support frame, 36" to top of belt approx.
- SHIPPING SIZE-W X H X L:4'W X 3'H X 26'L
- APPROX. WEIGHT-LBS:1500#
- QUANTITY:1
