1272166 - DRYER, DOUBLE CONE, VAC, 7CF, 100PCF, 30#JKT, 2HP, NO BAR [1]

  • MFD.BY:Baker Perkins
  • TYPE:Two jacketed conical shells of equal length joined at 180° to one another with cylindrical parallel shell section transition between the two cones. Rotation is around the horizontal axis, material tumbles out of one cone and into the other as the shell ro
  • MODEL:Conaform
  • CAPACITY:7CF working approx
  • MAX.PRODUCT DENSITY:100 PCF est
  • SIZE:32" I-Dia.approx. 32" long offset cones
  • MAT'L.CNSTRN-SHELL:316SS
  • MAT'L.CNSTRN-JACKET:CS
  • PRESSURE-SHELL:FV Hyd. to 1 Torr
  • CONNECTIONS:10"in /6"outlet w/valve
  • DRIVEN BY:2HP 3/60/230-460V approx.
  • DRIVEN VIA:V-belt, pinion/bullgear
  • LIQUIDS-SOLIDS BAR:No
  • COMMENTS:1" Rotary joint. On pedestal.
  • SHIPPING SIZE-W X H X L:4'W X 6'H X 8'L
  • APPROX. WEIGHT-LBS:2500#
  • QUANTITY:1
