- MFD.BY:CE Raymond
- DATE MFD:1997 approx.
- TYPE:Centrifugal action separates particles from dust-laden air.
- MODEL:DW [Double Whizzer]
- SIZE:4' dia.
- MAT'L CONSTRN-BODY:C.S.
- DRIVEN BY:5HP 3/60/460V, 1200 rpm. Fr.215T
- DRIVEN VIA:Belt. 1000rpm approx.
- DESIGN AIR FLOW:4000CFM approx.
- CONNECTIONS-AIR:8" dia feed tube
- PRIOR SVC:Acetylene Carbon Black powder and beads ~45 Microns
- COMMENTS:Superfine classifier. 4 Lug supports.
- SHIPPING SIZE-W X H X L:5'W X 5'H X 8'L
- APPROX. WEIGHT-LBS:2000#
- QUANTITY:1
