TYPE:Thin film evaporator. Product fed into one end of jacketed tubular shell where rotating element's centrifugal action directs product in a spiral path along entire inner surface of shell. Rotor blades feature a fixed clearance between blade tip and inner s
MODEL:CBVR-10 Reactor
ORIENTATION:Vertical
SURFACE AREA:10 Sq.Ft approx. 10"dia x 42'' shell length approx.
MAT'L.CNSTRN-SHELL:316LSS
MAT'L.CNSTRN-ROTOR:316LSS
MAT'L.CNSTRN-JACKET:Electrically traced
PRESSURE-SHELL:FV @ 387Deg F approx.
CONNECTIONS:Feed 2" Top-Vapor 3" Solids out- 3"'
DRIVEN BY:10HP 3/60/230-460v 1745 rpm Fr 215T TEFC Motor at top.
