1271078 - EVAP, WIPED FILM, 90SF, PFAUDLER, 304ELCSS SHELL, 316SS ROTOR, VERT. [3]

  • MFD.BY:Pfaudler
  • DATE MFD:1971
  • TYPE:Wiped film evaporator. Product fed into one end of jacketed tubular shell where rotating element's centrifugal action directs product in a spiral path along entire inner surface of shell. Rotor blades wipe clean shell surface behind product path. Liquid p
  • ORIENTATION:Vertical
  • SURFACE AREA:90 Sq.Ft./ 8.4Sq.M. approx.
  • MAT'L.CNSTRN-SHELL:304ELC SS [15/16" thick shell, 3/8" heads.]
  • MAT'L.CNSTRN-ROTOR:316SS
  • MAT'L.CNSTRN-JACKET:CS 1/2" thick. 41"OD x 10ft 1-1/4"long
  • PRESSURE-SHELL:FV [Atm# to 10Microns/15psi] @ 700°F. ASME. N.Bd.
  • EVAP. RATE-PPH H2O:1000 pph approx. depends on product, temp, etc.
  • CONNECTIONS:Shell: 2-1/2"inlet, 10" outlet. Condenser: 3" water inlet, 3" outlet. Jkt: 1-1/2"inlet, 1-1/2" outlet,
  • ROTOR:36" dia. Approx. w/channel entrainment separators.
  • DRIVEN BY:5HP 3/60/230-460V US Gear Motor. XP
  • DRIVEN VIA:Gearmotor, flange mounted. Rotor 68RPM. CW down.
  • CAPACITY:6000pph feed approx.
  • PRIOR SVC:Vitamin C Molecular Distillation. 1st & 2nd Stage
  • COMMENTS:Internal condenser 600 Sq.ft. area, 316SS tube bundle in bottom of unit. Wiper & Separator assembly has 56 total replacable wiper blade sections, 8 blade sets arranged on 45deg radials, RULON P material.n4 lug supports. Originally mounted in structural
  • SHIPPING SIZE-W X H X L:4'W X 4'H X 18'L
  • APPROX. WEIGHT-LBS:12650#
  • QUANTITY:3
