1271502 - HEAT EX, PLATE, 3842SF, 316SS, FV100#, A-LAVAL, M30FM [1]

  • MFD.BY:Alfa Laval Thermal, Inc.
  • DATE MFD:1995
  • TYPE:Plate heat exchanger. A series of vertical corrugated heat exchange plates are held together between the end plates of a horizontal screw compression type frame. The plates are separated by flexible, O-ring type, gaskets. Process fluid and heat exchange
  • MODEL:M30FM
  • AREA:3842SF
  • AREA-MAX.:3842SF
  • MAT'L CONSTRN-PLATES:316SS
  • MAT'L CONSTRN-FRAME:CS
  • PLATES:207 @ 0 .7 mm thick plates
  • FRAME CAPACITY:Pack length 24"approx
  • PRESSURE-PROCESS:FV100# MAWP @ 212°F. Hyd 172# ASME NB
  • PRESSURE-MEDIUM:FV100# MAWP @ 212°F. Hyd 172# ASME NB
  • CONNECTIONS-PROCESS:14” in/out. 1-pass
  • CONNECTIONS-MEDIUM:14” in/out. 1-pass
  • PRIOR SVC:Chemical
  • COMMENTS:Cooler
  • SHIPPING SIZE-W X H X L:2'W X 9'H X 9'6''L
  • APPROX. WEIGHT-LBS:8000#
  • QUANTITY:1
