- MFD.BY:Crane, Warrington, PA
- DATE MFD:2000 approx.
- TYPE:Centrifugal action pump. Seal-less
- MODEL:GVHS-10K-12H-1S Chempump code H
- SIZE:2 X 1 X 10
- ORIENTATION:Horizontal w/2 support brackets
- MAT'L.CNSTRN-CASE:316SS
- MAT'L.CNSTRN-IMPELLOR:316SS
- INLET:2'' Flanged
- DISCHARGE:1" Flanged
- JACKETED:No
- DRIVEN BY:20HP/15.5KW, 3/60/575V 3450rpm.17.6A
- DRIVEN VIA:Direct coupled
- CAPACITY-GPM:35-100 [35GPM @ 250FT HD to 100GPM @ 200FT HD]
- CAPACITY-FT.HEAD:250-200TDH, 100# @ 100°F
- PRIOR SVC:Condensate Water
- COMMENTS:Mechanical seals. Seal-Less Chempump..
- SHIPPING SIZE-W X H X L:1'W X 1'H X 2'L
- APPROX. WEIGHT-LBS:300#
- QUANTITY:1
