TYPE:Rotary sieve type screen. Separation is accomplished by size grading of a product as it passes through, or is retained on, a wire mesh screen with the required opening size to suit the process. The screen is a stationary and cylindrical through which prod
MODEL:Rota-Sifter
SIZE-DIA:12"
SIZE-LONG:36"
MAT'LS.CONSTRN-BODY:SS
MAT'LS.-SCREEN:SS
SCREEN MESH/SIZE:TBD
FEED:Gravity to horizontal feed screw
DRIVEN BY:5HP, 1750rpm approx [not included]
DRIVEN VIA:V-belt
CAPACITY:860Sq In screen area approx.
PRIOR SVC:Minerals
COMMENTS:Totally enclosed, high capacity separator. Outboard bearings. Less drive.
