- MFD.BY:Buffalo tank, Div Bethlehem Steel
- DATE MFD:1961
- TYPE:Pressure vessel.
- CAPACITY-GALLONS:3000 Gal.
- MAT'L CONSTRN-SHELL:CS A212B
- ORIENTATION:Horiz
- PRESSURE-SHELL:500#DP @450Deg F Hyd 750#
- CERTIFICATION-CODE/STD/NBD:ASME. N.Board.
- SHELL-DIAMETER:4' OD
- SHELL-LENGTH:29'9'' s-s
- SUPPORTS-QTY/TYPE/HIGH:2 saddles
- THICKNESSES-TOP HEAD:0.692"
- THICKNESSES-SHELL:0.825"
- THICKNESSES-BOTTOM HEAD:0.692"
- CONNECTIONS-SHELL:1.5'', 1/2" @ 3000#NPT coupling w/ball valve. 3" @300#RFF flange, drain.
- PRIOR SERVICE:Wax
- COMMENTS-ASME ETC.:New safety relief valve set @ 500psig.
- SHIPPING SIZE-W X H X L:4'W X 6'H X 34'L
- APPROX. WEIGHT-LBS:17500#
