- MFD.BY:General Welding Works Inc, Houston
- DATE MFD:1998
- TYPE:Storage tank, pressure vessel
- CAPACITY-GALLONS:6000 Gal. Approx
- MAT'L CONSTRN-SHELL:CS SA 516-70
- ORIENTATION:Vertical.
- PRESSURE-SHELL:FV210# MAWP @ 30-300Deg F. Hyd 365#
- CERTIFICATION-CODE/STD/NBD:ASME, N.Bd.
- SHELL-DIAMETER:6'
- SHELL-LENGTH:28'7'' Seam to bottom Flange face over short cone
- SUPPORTS-QTY/TYPE/HIGH:Support ring, 4 Lugs
- THICKNESSES-TOP HEAD:0.625'' 0.0625''Corr.Allow.
- THICKNESSES-SHELL:0.625'' 0.0625''Corr.Allow.
- THICKNESSES-BOTTOM HEAD:0.6875" 0.0625''Corr.Allow.
- CONNECTIONS-TOP HEAD:18", 8", 3" [3] 150# Flanged. [tbc]
- CONNECTIONS-SHELL:24"MH w/cover
- CONNECTIONS-BOTTOM HEAD:20" hinged bottom cover w/3" 150# RFSOF Flanged
- PRIOR SERVICE:Styrene Dryer. Regeneration via hot N2 purge, 75# @ 600Deg F
- COMMENTS-ASME ETC.:Top demister tower, 18" x 24" approx. Internal liquid sparger. External 3.5" R.G. insulation w/corrugated aluminum sheath external. Vessel CS only est.wt.16000#, Total empty wt. Per nameplate 61678# [w/insulation]
- SHIPPING SIZE-W X H X L:6'6''W X 6'6''H X 32'L
- APPROX. WEIGHT-LBS:16000#
