- DATE MFD:1990 approx
- TYPE:Tank with heating and or cooling abilities.
- CAPACITY-GALLONS:5750 Gal. Approx.
- ORIENTATION:Vert.
- MAT'L CONSTRN-SHELL:SS
- PRESSURE-SHELL:Atm#
- JACKET-TYPE/ZONES/BTM HD:NA
- PRESSURE-JACKET:NA
- MAT'L CONSTRN-JACKET:NA
- SHELL-DIAMETER:8'dia.
- SHELL-LENGTH:15'4" straight side.
- CONFIG.HEADS-TOP/BTM:Flat top head. Flat bottom
- SUPPORTS-QTY/TYPE/HIGH:Flat bottom
- CONNECTIONS-TOP/SH/BTM:Top- 16", 2" [2], 1-1/2", 1". Side- 18"MH, Bottom- 2".
- SHIPPING SIZE-W X H X L:8'W X 8'H X 20'L
- APPROX. WEIGHT-LBS:6000#
