- MFD.BY:Omnifab
- DATE MFD:1993
- TYPE:Tank with mixing abilities.
- CAPACITY-GALLONS:3300 Gal.
- MAT'L CONSTRN-SHELL:316LSS
- ORIENTATION:Vert
- PRESSURE-SHELL:ATM# @ -20/+200deg F
- SHELL-DIAMETER:7'6''OD
- SHELL-LENGTH:9'4''s-s
- AGITATOR-HP/RPM:Top Entering. Not included.
- BAFFLES-QTY/W X L:4
- THICKNESSES-TOP/SH/BTM:1/4" approx.
- CONNECTIONS-TOP HEAD:Top: 24", 6" (3), 4", 2", 1"
- CONNECTIONS-SHELL:Shell; 24"
- CONNECTIONS-BOTTOM HEAD:3" cbo
- CONFIG.HEADS-TOP/BTM:Dish/Dish
- PRIOR SERVICE:Blend/Let down
- COMMENTS-ASME ETC.:External fiber insulation w/aluminum sheathing. 2 lift lugs
- SHIPPING SIZE-W X H X L:8'W X 8'H X 12'10''L
- APPROX. WEIGHT-LBS:5200#
